Main Performance:
We improved this new generation machine according to the requirement of user, it is suitable for packaging all kinds of block，
granule and liquid material for large and medicine and drug, health medicine, food and candy, electronic, hardware etc.
It features of moisture proof,dust proof which is improving the grades of packaging.
It is suitable for producing a single variety production of large quantities.
| Model | CP-250 | CP-320 | CP-420 |
| Power(kw) | 8.5 | 8.5 | 10 |
| Capacity(sheet/h) | 3600-7200 | 3600-9000 | 3600-12000 |
| Max.PVC film width(mm) | 250 | 320 | 420 |
| Stroke range(mm) | 40-160 | 40-160 | 40-160 |
| Max.forming blister depth(mm) | 25 | 25 | 25 |
| Thickness of PVC film(mm) | 0.25-0.5 | 0.25-0.5 | 0.25-0.5 |
| Thickness of cover film(mm) | 0.02-0.035 | 0.02-0.035 | 0.02-0.035 |
| Air consumption(ml/min) | ≥0.36 | ≥0.36 | ≥0.36 |
| Dimension(mm) | 3200x700x1850 | 3600x750x1850 | 4750x900x1650 |
| Gross weight(kg) | 1500 | 1800 | 2500 |
