Speed: 60-80 tubes/min
With one machine have possibility to work with plastic, laminated and aluminium tubes.
Main Features
1.Adopt Japanese Mitsubishi PLC and Touch Screen.
2.The tube filling and sealing machine is made of high quality stainless steel AISI 304.
3.All elements having contact with product are made of high quality stainless steel AISI 316.
4.Filling accuracy error: <±1% of volume,
5.Hot air sealing technology(plastic and laminated tube).
6.Double fold closing(aluminum tube).
7. Output up to 60-80 tubes / minute.
| Model | CP-60A | CP-60B |
| Tube material | Plastic Tube | Aluminium Tube |
| Speed | 40-60tubes/min | 40-60tubes/min |
| Tube Diameter | 10-42mm | 10-42mm |
| Tube length | 50-250mm | 50-250mm |
| Filling volume | 5-500ml | 5-500ml |
| Filling Accuracy | ≤±1% | ≤±1% |
| Power Supply | 5.2kw | 3kw |
| Air Consumption | ≥0.6mpa 20m³/h | ≥0.6mpa 20m³/h |
| Machine Dimension | 2500x1020x 1980mm | 2500x1020x1980mm |
| Machine Weight | 1100kg | 1100kg |
